Overview of angles that can be archived by a middle part of x studs wide (cols) and y plates height (rows).
| × | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2 | 15.2 | 11.4 | 9.1 | 7.6 | 6.5 | 5.7 | 5.1 | 4.6 | 4.2 | 3.8 | 3.5 | 3.3 | 3.1 | 2.9 | 2.7 |
| 3 | 29.9 | 22.6 | 18.2 | 15.2 | 13.0 | 11.4 | 10.2 | 9.1 | 8.3 | 7.6 | 7.0 | 6.5 | 6.1 | 5.7 | 5.4 |
| 4 | 43.6 | 33.4 | 27.0 | 22.6 | 19.5 | 17.1 | 15.2 | 13.7 | 12.5 | 11.4 | 10.5 | 9.8 | 9.1 | 8.6 | 8.1 |
| 5 | 56.1 | 43.6 | 35.5 | 29.9 | 25.8 | 22.6 | 20.2 | 18.2 | 16.6 | 15.2 | 14.0 | 13.0 | 12.2 | 11.4 | 10.8 |
| 6 | 67.4 | 53.1 | 43.6 | 36.9 | 31.9 | 28.1 | 25.1 | 22.6 | 20.6 | 18.9 | 17.5 | 16.3 | 15.2 | 14.3 | 13.4 |
| 7 | 77.3 | 61.9 | 51.3 | 43.6 | 37.8 | 33.4 | 29.9 | 27.0 | 24.6 | 22.6 | 20.9 | 19.5 | 18.2 | 17.1 | 16.1 |
| 8 | 86.1 | 70.0 | 58.5 | 50.0 | 43.6 | 38.6 | 34.6 | 31.3 | 28.6 | 26.3 | 24.3 | 22.6 | 21.1 | 19.9 | 18.7 |
| 9 | 93.7 | 77.3 | 65.2 | 56.1 | 49.1 | 43.6 | 39.1 | 35.5 | 32.4 | 29.9 | 27.7 | 25.8 | 24.1 | 22.6 | 21.3 |
| 10 | 100.4 | 84.0 | 71.5 | 61.9 | 54.4 | 48.5 | 43.6 | 39.6 | 36.2 | 33.4 | 31.0 | 28.8 | 27.0 | 25.4 | 23.9 |
| 11 | 106.3 | 90.0 | 77.3 | 67.4 | 59.5 | 53.1 | 47.9 | 43.6 | 40.0 | 36.9 | 34.2 | 31.9 | 29.9 | 28.1 | 26.5 |
| 12 | 111.4 | 95.5 | 82.7 | 72.5 | 64.3 | 57.6 | 52.1 | 47.5 | 43.6 | 40.3 | 37.4 | 34.9 | 32.7 | 30.8 | 29.0 |
| 13 | 116.0 | 100.4 | 87.7 | 77.3 | 68.9 | 61.9 | 56.1 | 51.3 | 47.1 | 43.6 | 40.5 | 37.8 | 35.5 | 33.4 | 31.5 |
| 14 | 120.0 | 104.9 | 92.2 | 81.8 | 73.2 | 66.0 | 60.0 | 54.9 | 50.6 | 46.9 | 43.6 | 40.8 | 38.2 | 36.0 | 34.0 |
| 15 | 123.6 | 108.9 | 96.5 | 86.1 | 77.3 | 70.0 | 63.8 | 58.5 | 54.0 | 50.0 | 46.6 | 43.6 | 40.9 | 38.6 | 36.5 |
| 16 | 126.9 | 112.6 | 100.4 | 90.0 | 81.2 | 73.7 | 67.4 | 61.9 | 57.2 | 53.1 | 49.6 | 46.4 | 43.6 | 41.1 | 38.9 |
